| LCD Panel |
- 24" FHD LCD
- 350 nits
- 1920 x 1080 pixcel
|
| CPU |
- Intel® Core™ Ultra 7/5 Processor (Series 1), up to 45W
|
| Chipset |
|
| System Memory |
- 2 x DDR5-5600 SO-DIMM, up to 96 GB
|
| BIOS |
|
| COM |
- 1 x COM (RS-232) with 1.5kV isolation (optional)
|
| USB |
- 4 x USB 3.2 Type-A
- 1 x USB Type-C, supports PCIe Gen 3 x4 lanes/USB 3.2/PD 15W/DP Alt mode
|
| Ethernet |
- 2 x 10/100/1000/2500 Mbps Ethernet (1.5kV isolation, Intel® I226-LM)
|
| Display |
|
| Audio |
- 2 x audio (2W speakers, HD codec audio with Mic-in/Line-out using Realtek ALC888s)
|
| Storage |
- 2 x M.2 Key M 2280 support NVMe SSD
|
| Expansion |
- 1 x PCIe Gen 4 x4 (x16 slot) for MXM GPU module
- 1 x M.2 Key E 2230 for Wi-Fi 6E/BT5.2
|
| Others |
- TPM 2.0
- 1 x RFID card reader (optional)
|
| Touchscreen |
- Projected capacitive 10-point multi-touch
|
| Front Bezel |
- IP65 front bezel and IPX1 full enclosure design
|
| Power Consumption |
|
| Power Supply |
- 24V DC input with medical-grade 250W PSU
|
| Watchdog Timer |
- 255 levels, 0 to 255 sec.
|
| Operating Temperature |
- 0°C to +40 °C (+32°F to +104°F)
|
| Relative Humidity |
- Operating humidity: 10% to 95% @ +40°C (+104°F)
- Storage humidity: 95% @ +40°C (+104°F)
|
| Vibration |
|
Dimensions
(W x D x H) |
- 548 x 349.4 x 61.7 mm (21.57" x 13.75" x 2.43")
|
| Weight (net/gross) |
|
| Certifications |
- CE, FCC Part 18
- IEC 60601-1 Edition 3.2 compliant
|
| EOS |
- Windows® 10 IoT Ent, Windows® 11 IoT Ent
|
| Mounting |
- VESA arm
- Panel mount
- Desktop stand
- Wall mount
|
